Terminal Marker
Technical Details
| Pg Blind Stop - Grey | ||||||
|---|---|---|---|---|---|---|
| Cat. No. Grey | Size | Thread Diameter D (mm) | Thread Length L (mm) | Spanner Size (mm) | Clamping Range (mm) | Standard Pack (Pieces) |
| ABP-01 | Pg 7 | 12.5 | 8 | 15 | 3 - 6.5 | 50 |
| ABP-02 | Pg 9 | 15.2 | 8 | 19 | 04 - 08 | 50 |
| ABP-03 | Pg 11 | 18.6 | 8 | 22 | 05 - 10 | 50 |
| ABP-04 | Pg 13.5 | 20.4 | 10 | 24 | 06 - 12 | 50 |
| ABP-05 | Pg 16 | 22.5 | 10 | 27 | 10 - 14 | 50 |
| ABP-06 | Pg 21 | 28.3 | 11 | 33 | 13 - 18 | 25 |
| ABP-07 | Pg 29 | 37 | 11 | 42 | 18 - 25 | 20 |
| ABP-08 | Pg 36 | 47 | 13 | 53 | 22 - 32 | 10 |
| ABP-09 | Pg 42 | 54 | 13 | 60 | 30 - 38 | 10 |
| ABP-10 | Pg 48 | 59.3 | 14 | 65 | 34 - 44 | 10 |
